Datalogic falcon x3+ User Manual

USE AND FUNCTIONING
57
4
4.6.2 DL Buttons
You can use DL Buttons Tab to associate specific keys, such as <F1>-<F10>, with
specific applications.
From the control panel main window, double tap the DL Buttons icon.
On the DL Buttons tab, customize the program hardware buttons to launch your most
used applications. Under ‘Select a button’, select the button you want to assign a
function to, and then select a program from ‘Assign a function’.

Datalogic falcon x3+ Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	65536 colors
Flash memory	1 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Processor family	PXA 310
Built-in processor	PXA310
Processor frequency	0.806 GHz
Processor manufacturer	Marvell
GPS (satellite)	No
Operating system installed	Windows Embedded Handheld 6.5
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Rear camera resolution (numeric)	3.1 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Battery capacity	5200 mAh
RFID reader	-
Product color	Black
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128), Intelligent Mail, PLANET, POSTNET, RM4SCC / KIX, U.P.C.
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	168 mm
Width	88 mm
Height	225 mm
Weight	674 g
