GRYPHON™ BT DEFAULT CONFIGURATION
DATA FORMAT
code identifier disabled, field adjustment disabled, code length tx not
transmitted, character replacement disabled, address stamping = disabled,
address delimiter = disabled.
POWER SAVE
scan rate 270 scans/s.
READING PARAMETERS
operating mode hand-held, hardware trigger, trigger active level, no timeout,
Flash On = 1 sec, Flash Off = 0.6 sec, one read per cycle, safety time 0.5
sec, beeper intensity high, tone 2, beeper type monotone, beeper length
short, good read spot duration medium, beeper control for radio response =
ON.
DECODING PARAMETERS
ink spread enabled, overflow control enabled, interdigit control enabled,
Puzzle Solver™ disabled, decoding safety = one read.
CODE SELECTION
enabled codes
BT200
Code PDF417
EAN 8/EAN 13 / UPC A/UPC E without ADD ON
check digit transmitted, no conversions
Interleaved 2/5
check digit control and transmission, variable length code;
4-99 characters
Standard Code 39
no check digit control, variable length code; 1-99 characters
BT100
BT200
Code 128, variable length code; 1-99 characters
disabled codes
BT100
BT200
EAN 128, ISBT128, Code 93, Codabar, pharmaceutical
codes, Codablock-A, Codablock-F Standard and EAN, MSI,
Plessey, Telepen, Delta IBM, Code 11, Code 16K, Code 49
RSS family

Datalogic GRYPHON BT100 Specifications

General

Scan speed	270 sec/page
Sensor type	CCD
Tilt angle range	-35 - 35 °
Decoding standards	1D/Linear Codes:\\tAutodiscriminates all standard 1D codes including GS1 Databar linear codes; Stacked Codes: Code 16K; Code 49; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional;
Dimensions (WxDxH)	208 x 107 x 56 mm
Standard interfaces	RS-232
Product color	Gray
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	280 g
