Datalogic Gryphon GBT4400 User Manual

Positioning the Base Station
4Gryphon™ GBT4400
Figure 3 - Vertical Position
This position is preferred when lack of room on the desktop
recommends the scanner to be left vertical during recharging.
1. Insert the appropriate parts for the desired base sta-
tion position.
2. Using your thumbs, push open the plastic tabs on the
bottom of the base to free the wing holders.
Tab
Tab

Datalogic Gryphon GBT4400 Specifications

General

Connectivity	Bluetooth
IP Rating	IP52
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Dimensions	18.1 x 7.1 x 10.0 cm / 7.1 x 2.8 x 3.9 in
Scanner Type	2D Imager
Battery	Lithium-Ion
Drop Resistance	1.8 m (6 ft) to concrete
Light Source	Red LED
Image Sensor	CMOS
Decode Capabilities	1D, 2D, Postal Codes, Stacked Codes
Scan Rate	60 frames/sec
Interface	USB, RS-232, Keyboard Wedge
Power Supply	5 VDC +/- 10%
Humidity	5 to 95% non-condensing
Drop Specification	1.8 m (6 ft) to concrete
