Maintenance LED (Red LED) - Continued
Blink red, 4 quick pulses
(single slot)
EOC (end of charge) timeout error. The WLC EOC
signal has been kept enabled by the terminal
for too much time. Typically, it is caused by a
bug in the terminal firmware. The power
transfer is disabled.
Blink red, 5 quick pulses
(single slot)
WLC generic error. The WLC system seems
unstable and unable to setup a stable power
transfer within a reasonable time. The power
transfer is suspended. Solution: try to extract
the device from the cradle and to re-insert it
again.
Blink red, 6 quick pulses
(single slot)
Device charging error.
Blink red, 7 quick pulses
(single slot)
Wrong daisy chain configuration error. More
than two cradles are connected in daisy chain.
Solution: remove exceeding cradles from the
chain.
Solid red (middle slot only) Firmware upgrade.
NOTE
For further information on the Joya Touch 3-Slot Cradle,
refer to the Joya Touch 3-Slot Cradle Quick Start Guide,
included in the cradle’s box, and to the Joya Touch 3-Slot
Cradle Installation Guide, downloadable from our website
www.datalogic.com.
