A-2 Magellan
®
1400i
Physical Properties
Electrical Parameters
Environmental Parameters
Other Parameters
Parameter Specification
Dimensions (Scanner only): 66mm x 82mm x 154mm ( 2.6” x 3.23” x 6”)
Dimensions (Scanner w/
Stand):
97mmx 82mm x 181mm (3.82” x 3.23” x 7.13”)
Weight (Scanner) 9 oz.
Weight (Base Station) 15.7 oz.
Parameter Specification
Operating Voltage
(Two Models)
5V unit = 5.0V ± 5%
12V unit = 8-14V ± 5%
Input Current
Operating (idle)
Operating (label read)
Surge Current (< 30 ms)
<350mA
<450 mA
<650mA
Parameter Specification
Mechanical Shock Multi 1.2m drops
Contaminants
Water and Dust IP52
Temperature Ranges:
Operating 32q F to +104q F (0q C to +40q C)
Storage -40q F to +158q F (-40q C to + 70qC)
Ambient Light Indoor <6000 lux
Ambient Light Outdoor <86,100 lux
Humidity 5 to 95% non-condensing
Beeper/Speaker 70-85dBA at a distance of 3’-3” (1 meter)
Vibration Retail/Office
Parameter Specification
EAS Support YES (Checkpoint)
