Datalogic Magellan 2300HS Product Reference Guide

Product Reference Guide 2-1
Chapter 2
Site Preparation and Installation
This chapter outlines the procedures for unpacking the scanner, verifying
function, preparing the countertop or wall, routing cables, and installing
the scanner.
Unpacking
To u n pa c k t h e u ni t :
• Inspect the package for signs of damage that may have occurred dur-
ing shipping. If damage is found, report it to your carrier immedi-
ately.
• Lift any accessories from the box, including the AC/DC Power Sup-
ply, and the Quick Reference Guide.
• Familiarize yourself with the Quick Reference Guide. Leave the
guide at the checkstand when the installation is complete.
• Remove the protective packing and carefully lift the scanner from
the carton. Be sure to save the box and all packing material. In the
event of failure, the unit must be returned to the factory in its origi-
nal packaging
.
Proceed to the Operational Verification instructions below.

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
