Code 39 Enable
Product Reference Guide 5-203
Code 39 Fixed Length 1
This feature specifies Code 39 first fixed length.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code,
SET CODE 39 FIXED LENGTH 1 below. You’ll
need to cover any unused bar codes on this and the facing page to
ensure that the scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired fixed label length. The selectable range for this
option is 00 to 50. Pad all single digit numbers with a leading zero
to yield a two-digit entry (00-50).
4. Complete the programming sequence by scanning the SWITCH
bar code.
SET CODE 39 FIXED LENGTH 1
NOTE
This applies when Code 39 Length Control is set to fixed-length
decoding.
The minimum decodable length is four when an optional check
character is present.

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
