Product Reference Guide F-11
2-Digit Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']E1'.
• length of Supplemental data including prefix must be 5. Total
required length is 21 for EAN-13 and 16 for EAN-8.
• Examples: addon portion is highlighted data is underlined.
5-Digit Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']E2'.
• Length of supplemental data including prefix must be 8. Total
required length is 24 for EAN-13 and 19 for EAN-8.
• Examples: addon portion is highlighted data is underlined.
UPC-A 2-Digit addon
']E00060992011187]E1
12'
UPC-E 2-Digit addon
']E00000000998875]E1
12'
EAN-8 2-Digit addon
']E400210126]E1
12'
EAN-13 2-Digit addon
']E01101234567891]E1
12'
UPC-A 5-Digit addon
']E00060992011187]E2
12345'
UPC-E 5-Digit addon
']E00000000998875]E2
12345'
EAN-8 5-Digit addon
']E400210126]E2
12345'
EAN-13 5-Digit addon
']E01101234567891]E2
12345'

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
