F-12 Magellan
TM
2200VS and 2300HS
Code 128 Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']C0'.
• length of Supplemental data including prefix is variable but must be
at least 9.
• Examples: addon portion is highlighted data is underlined.
Bookland
• The 'Bookland' / ISBN code will be formatted as a vendor specific
AIM label.
• Prefix must be ASCII characters ']X0'.
• length of label data including prefix is 13.
• Examples: ']X01234567890'.
Code 39
• Check character must be included in label data.
• Label length including start, stop and check characters and exclud-
ing prefix characters must meet requirements imposed by the main
scanner's fixed or variable label length control for this symbology
type.
• Start and stop characters "*" must be included in label.
• Prefix must be ASCII characters ']A0' or ']A1'.
• Example: '*]A0Code 39.TEST*'.
UPC-A Code 128 addon
']E00060992011187]C0
81000009
51'
UPC-E Code 128 addon
'E00000000998875]C0
810000095
1'
EAN-8 Code 128 addon
']E400210126]C0
8100000951'
EAN-13 Code 128 addon
']E01101234567891]C0
81000009
51'

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
