Datalogic Magellan 2300HS Product Reference Guide

Programming Overview
Product Reference Guide 5-5
Programming Session
A typical programming session is conducted as follows:
1. Scan the SWITCH bar code to place the scanner in Programming
Mode. Depending upon its current programming, the scanner may
emit a beep or beeps, indicating it has read the bar code and the
green LED will flash on and off slowly while the scanner remains in
Programming Mode. Normal scanning functions are disabled.
2. Scan the programming bar code(s) that is (are) specially encoded to
make the desired changes. With few exceptions
1
, the scanner will
emit a triple beep each time you scan a valid programming bar code.
Additionally, when programming a feature requiring you to scan single
digits to set a multi-digit number, such as Minimum Label Length, scan-
ning the SWITCH bar code (or any item tag/item value bar code) before
completing all input will result in an error tone and cause the scanner to
exit Programming Mode. Under these circumstances, the current feature
you were trying to set is thrown out; any previous bar codes scanned dur-
ing the session will take effect.
1. Some features, such as Minimum Label Length, require you to select the label’s length by scan-
ning a series of single-digit bar codes. A single ‘good read’ beep is sounded when scanning these
single digits in Programming Mode. Only the final required digit in the sequence will produce a tri-
ple beep when scanned, indicating a successfully programmed feature.
NOTE
Not all features are available for all interfaces and the scanner
will sound an error tone when scanning programming bar codes
for features invalid to the current interface. Only features sup-
ported by the currently active interface will be implemented.
NOTE
If a bar code is scanned that changes the scanner’s interface, all
previous configuration items scanned in the programming ses-
sion are lost.

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
