Datalogic Magellan 2300HS Product Reference Guide

Programming
5-38 Magellan
TM
2200VS and 2300HS
Interface Type — continued
To select the desired interface:
1. Disconnect current interface cable(s) if currently connected.
2. Scan the SWITCH bar code
3. Scan the bar code representing the appropriate interface located on
the following pages. You’ll need to cover any unused bar codes adja-
cent to and on any facing pages to ensure the scanner reads only the
bar code you intend to scan.
4. Complete the programming sequence by scanning the SWITCH
bar code.
5. Connect new interface cable(s).
CAUTION
Great care should be taken to select the correct interface type,
since you can cause damage to the scanner and/or POS terminal
by attempting to change to an incompatible interface. ALWAYS
make interface selections with the host cable DISCONNECTED.
NOTE
When an interface is selected, the scanner loads the factory con-
figuration for that interface as the selection is made, erasing any
and all custom configuration that may have previously been done.
NOTE
Once the correct interface has been set, it will be necessary to pro-
ceed to the appropriate pages in this manual that select parameters
and options for that interface. For example, if RS-232 is selected,
turn to the pages in this manual headed as features specific to the
RS-232 interface.

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
