Datalogic Matrix 210 Programming Manual

HOST MODE PROGRAMMING
22
4
4 MATRIX 210™ PARAMETERS LIST
4.1 OPERATING MODE
25 PIN CONNECTOR MODELS
ETHERNET MODELS
PARAMETER TYPE SEL STRING DATA
OPERATING MODES
Operating Mode 1 1 ESC A A 0 = One Shot
1 = Continuous
2 = Phase Mode
Reading Phase ON 4 9 ESC A B 1 = Ext. Trig. Lead. Edge
2 = Ext. Trig. Trailing Edge
4 = Main Port String
8 = Auxiliary Port String
16 = Input 2 Leading Edge
32 = Input 2 Trailing Edge
64 = Ethernet String
128 = Ethernet IP Input Leading Edge
256 = Ethernet IP Input Trailing Edge
512 = Fieldbus String
1024 = Fieldbus Input Leading Edge
2048 = Fieldbus Input Trailing Edge
4096 = ID-NET String
Acquisition Trigger
(Phase Mode)
4 10 ESC A C 1 = Continuous
2 = Multi-Delay
4 = Periodic
8 = Input 2 Leading Edge
16 = Input 2 Trailing Edge
32 = Main Port String
64 = Auxiliary Port String
128 = Ext. Trig. Leading Edge
256 = Ext. Trig. Trailing Edge
512 = Ethernet String
1024 = Ethernet IP Trigger Leading Edge
2048 = Ethernet IP Trigger Trailing Edge
4096 = Fieldbus String
8192 = Fieldbus Input Leading Edge
16384 = Fieldbus Input Trailing Edge
32768 = ID-NET String
Acquisition Trigger
Status
1 1 ESC A P 0 = Always Enabled
1 = Enabled When Input 2 Open
2 = Enabled When Input 2 Closed
Acquisition Trigger
Period (ms)
(Phase Mode)
0 ESC A G Range: 17 to 60000
