HOST MODE PROGRAMMING
2
2
2 PROGRAMMING COMMANDS
2.1 CONNECTION TO DEVICE
DESCRIPTION HOST COMMAND REPLY MESSAGE
1 Enter Host Mode <ESC> [ C <ESC> H <CR><LF>
After entering this command, the device responds with the first reply message and
then waits for the following command.
2 Enter Programming Mode <ESC> [ B <ESC> Q <CR><LF>
After entering this command, the device responds with the second reply message
and or one or more programming strings as shown in Chapter 3.
2.2 DISCONNECTION FROM DEVICE
DESCRIPTION HOST COMMAND REPLY MESSAGE
1
End of Single Parameter
Programming Sequence
<ESC> I A #
<ESC> K <CR><LF>
<ESC> W 1 <CR><LF>
This message must always be transmitted after each escape programming string
(refer to paragraph 3.2).
If the progr
amming is correct, the device confirms with the first reply message. If
programming contents are wrong (i.e. a typing error in the programming string) or
due to a transmission error, Matrix replies with the second error message.
2
Exit Programming Mode and
Data Storage
<ESC> I A !
<ESC> I A <space>
<ESC> K <CR><LF>
<ESC> W 1 <CR><LF>
This command must always be transmitted to exit from programming mode.
It defines whether the configuration will be saved in the temporary (RAM) or
permanent (FLASH) memory (refer to paragraph 3.4).
If the progr
amming is correct, the device updates the configuration and confirms
with the first reply message. If programming contents are wrong (i.e. a typing error
in the file) or due to a transmission error, Matrix replies with the second error
message and programming data will not be updated in this case.
3 Exit Host Mode <ESC> [ A <ESC> X <CR><LF>
This command must always be transmitted to end the programming session. On exit
from Host Mode, the device is initialized with the new programming already saved in
the temporary and/or permanent memory.
