Datalogic Matrix 210 Programming Manual

PROGRAMMING STRINGS
5
3
3 PROGRAMMING STRINGS
3.1 DEFINITIONS
Common definitions for each parameter are:
Depth (parameter depth)
Parameter depth indicates if the parameter is made up of a vector of values or a single value
(e.g. Gain parameter has depth > 1 since we have one Gain value for each recipe allowed;
Operating Mode parameter has depth =1).
Depth must be specified when preparing the escape programming string.
Example
: Image Acquisition Setting #3 enable/disable.
Label: Image Acquisition Setting
Escape Sequence <ESC> a #n [selection]
Type (parameter type)
Parameter type is essential in order to decide the features of the serial command used to set
its new value. Types are:
Type 0
: Integer (numeric)
Type 1
: Enumerative
Type 2
: String
Type 3
: Bit Field
Type 4
: At Least One
Label
Information available in the Parameters window of the VisiSet™ configuration tool.
The other definitions change according to the parameter type.
Integer (Type = 0)
Range
Minimum and maximum values allowed for the parameter.
Default
Default value (integer).

Datalogic Matrix 210 Specifications

General

Resolution (mm)	0.1 mm
Drop Specification	1.5 m
Technology	Imager
Interface	RS-232, USB, Ethernet
Illumination	Red LED
Scan Rate	60 fps
Light Source	White or Red LED
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 60°C
Humidity	90% non-condensing
Dimensions (mm)	170 x 85 x 160 mm
Power Supply	5V DC
