MATRIX 210™ PARAMETERS LIST
65
4
PARAMETER TYPE SEL STRING DATA
AUTOLEARNING SETUP
Image Acquisition
Setting
0 ESC N J Range: 1 to 10
Calibration Mode 1 1 ESC N K 0 = Gain Only
1 = Exposure Time Only
2 = Exposure Time And Gain
Code Setting Mode 1 1 ESC N L 0 = General Purpose
1 = 2D Codes Only
2 = 1D Codes Only
3 = Direct Marking Only
Add New Symbology 1 1 ESC N M 0 = Disabled
1 = Enabled
Store Memory 1 1 ESC N B 0 = Temporary
1 = Permanent
Store Match Code
Policy
1 1 ESC N z 0 = First Free Slot
1 = First Slot
Autolearning Timeout
(sec)
0 ESC N O Range: 1 to 300
(0 = Disabled)
POSITIONING SETUP
Image Acquisition
Setting
0 ESC N P Range: 1 to 10
Positioning Mode 1 1 ESC N Q 0 = Standard
1 = Accurate
Positioning Tolerance
(mm)
0 ESC N R Range: 1 to 1000
Positioning Timeout
(sec)
0 ESC N S Range: 1 to 300
(0 = Disabled)
4.15 DISPLAY
25 PIN CONNECTOR MODELS + CBX DISPLAY MODULE
ETHERNET MODELS + CBX DISPLAY MODULE
PARAMETER TYPE SEL STRING DATA
DISPLAY
Display Language 1 1 ESC U A 0 = English (United States)
1 = French (France)
2 = German (Germany)
3 = Italian (Italy)
4 = Japanese (Japan)
Array Layout Monitor 1 1 ESC U B 0 = Disabled
1 = Enabled
