HOST MODE PROGRAMMING
64
4
PARAMETER TYPE SEL STRING DATA
Green Spot Activation
Events (Match Code
enabled)
3 4 ESC N X 0 = None
1 = Decoding
2 = Right Code
4 = Wrong Code
8 = No Read
16 = Multiple Read
Green Spot
Deactivation Timeout
(sec)
O ESC N Y Range: 1 to 300
(0 = Disabled)
COM LED Function 1 1 ESC N C 0 = Main COM Port RX
1 = Main COM Port TX
2 = Network Present
3 = Network RX
4 = Network TX
Aiming System Status 1 1 ESC N Z 0 = Disabled
1 = Enabled
LEDs Deactivation
Timeout (sec)
0 ESC N V Range: 0 to 300
Partial Read Treated As 1 1 ESC N a 0 = No Read
1 = Complete Read
Multiple Read Treated
As
1 1 ESC N f 0 = No Read
1 = Complete Read
BEEPER
Status 1 1 ESC N T 0 = Disabled
1 = Enabled
Activation Events
(Match Code disabled)
3 4 ESC N D 0 = None
1 = Decoding
2 = Complete Read
4 = Partial Read
8 = No Read
16 = Multiple Read
Activation Events
(Match Code enabled)
3 4 ESC N E 0 = None
1 = Decoding
2 = Right Code
4 = Wrong Code
8 = No Read
16 = Multiple Read
Deactivation Timeout
(ms)
0 ESC N F Range: 1 to 1500
TEST MODE SETUP
Image Acquisition
Setting
0 ESC N b Range: 1 to 10
Number Of Samples 0 ESC N c Range: 5 to 1000
Test Mode Data TX 3 3 ESC N d 0 = None
1 = Auxiliary Port
2 = Main Port
4 = ID-NET
8 = Host Interface Port
Test Mode Exit Timeout
(sec)
0 ESC N e Range: 1 to 300
(0 = Disabled)
