MATRIX 210™ PARAMETERS LIST
71
4
PARAMETER TYPE SEL STRING DATA
44 = Pharmacode
45 = Aztec Code
46 = OCR OCV
47 = Intelligent Mail
48 = Micro QR Code
49 = Swedish Postal
50 = GS1 Data Matrix
51 = Matrix 2 of 5
52 = Standard 2 of 5
53 = MSI
54 = Code 32
55 = Locator Edge
Data #n 2 ESC z #n Length: 0 to 1042
Wildcard Character
#n
2 ESC Y #n Length: 1
Placeholder
Character #n
2 ESC Z #n Length: 1
NOTE
Special characters <FE
H
> and <FD
H
> must be added after #n in the
programming string to indicate parameter Depth > 9. Refer to paragraph 3.2
for further details.
4.18 SYMBOL VERIFICATION
PARAMETER TYPE SEL STRING DATA
ISO-IEC 16022-18004
Status 1 1 ESC R A 0 = Disabled
1 = Enabled
ISO-IEC 15415-15416 SETUP
Aperture Mode 1 1 ESC R B 0 = Automatic
1 = Custom
Aperture (mils) 0 ESC R C Range: 0 to 1000
Angle 0 ESC R D Range: 0 to 90
Light Wavelength (nm) 1 1 ESC R E 0 = White
1 = 660
2 = 760
ISO-IEC 15415
Status 1 1 ESC R F 0 = Disabled
1 = Enabled
ISO-IEC 15416
Status 1 1 ESC R G 0 = Disabled
1 = Enabled
Grade Type 1 1 ESC R H 0 = 10 Scans
1 = Media
2 = Media & 10 Scans
AS9132A
Status 1 1 ESC R I 0 = Disabled
1 = Enabled
