MATRIX 210™ PARAMETERS LIST
37
4
PARAMETER TYPE SEL STRING DATA
ETHERNET/IP
Master Input Area Size 0 ESC S a Range: 8 to 144
Master Output Area
Size
0 ESC S b Range: 8 to 144
Data Flow Control 1 1 ESC S c 0 = Disabled
1 = DAD Driver
Data Consistency 1 1 ESC S d 0 = Disabled
1 = Enabled
IP Addressing Mode 1 1 ESC S e 0 = Static Assignment
1 = DHCP
2 = Remote Assignment
IP Address
(Static Addressing)
2 ESC S f Length: 1 to 15
Subnet Mask (Static
Addressing)
2 ESC S g Length: 1 to 15
Gateway Address
(Static Addressing)
2 ESC S h Length: 1 to 15
CC-LINK
Master Input Area Size 0 ESC S i Range: 2 to 126
Master Output Area
Size
0 ESC S j Range: 2 to 128
Node Address 0 ESC S k Range: 0 to 64
Data Flow Control 1 1 ESC S l 0 = Disabled
1 = DAD Driver
Data Consistency 1 1 ESC S m 0 = Disabled
1 = Enabled
Baud Rate 1 1 ESC S n 0 = 56kbps
1 = 625kbps
2 = 2.5Mbps
3 = 5Mbps
4 = 10Mbps
Version
(CC-Link Controller
Software Version)
0 ESC S o Range: 1 to 2
CAN OPEN
Master Input Area Size 0 ESC S p Range: 8 to 144
Master Output Area
Size
0 ESC S q Range: 8 to 144
Node Address 0 ESC S r Range: 0 to 128
Data Flow Control 1 1 ESC S s 0 = Disabled
1 = DAD Driver
Data Consistency 1 1 ESC S t 0 = Disabled
1 = Enabled
PROFINET IO
Master Input Area Size 0 ESC S u Range: 8 to 56
Master Output Area
Size
0 ESC S v Range: 8 to 56
Data Flow Control 1 1 ESC S w 0 = Disabled
1 = DAD Driver
Data Consistency 1 1 ESC S x 0 = Disabled
1 = Enabled
