Datalogic Matrix 210

MATRIX 210™ PARAMETERS LIST
43
4
PARAMETER TYPE SEL STRING DATA
INTERLEAVED 2 OF 5
Status 1 1 ESC H N 0 = Disabled
1 = Enabled
Check Digit Status 1 1 ESC H O 0 = Disabled
1 = Enabled
Check Digit
Transmission
1 1 ESC H P 0 = Disabled
1 = Enabled
Narrow Margins 1 1 ESC H Q 0 = Disabled
1 = Enabled
Minimum Number of
Characters
0 ESC H M Range: 2 to 60
PHARMACODE
Status 1 1 ESC H V 0 = Disabled
1 = Enabled
Output Format 1 1 ESC H W 0 = Binary
1 = Encoded
Minimum Bar Count 0 ESC H X Range: 4 to 16
Maximum Bar Count 0 ESC H Y Range: 4 to 16
Decoded Minimum
Value
0 ESC H Z Range: 15 to 131070
Decoded Maximum
Value
0 ESC H a Range: 15 to 131070
Code Orientation 1 1 ESC H b 0 = Horizontal
1 = Vertical
Direction of Decoding 1 1 ESC H c 0 = Normal
1 = Reverse
Colored Bars Check 1 1 ESC H B 0 = Disabled
1 = Enabled
UPC/EAN FAMILY
Status 1 1 ESC H d 0 = Disabled
1 = Enabled
ADDON 2 and 5 Status 1 1 ESC H e 0 = Disabled
1 = Enabled
2 = Enabled (+AddOn 2 No Quiet Zone)
Expand UPC E0-E1
symbols
1 1 ESC H f 0 = Disabled
1 = Enabled
Narrow Margins 1 1 ESC H g 0 = Disabled
1 = Enabled
Margin Size (%)
(% of narrow module
size)
1 1 ESC H w 0 = 200
1 = 250
2 = 300
3 = 350
4 = 400
5 = 450
CODABAR
Status 1 1 ESC H i 0 = Disabled
1 = Enabled
Narrow Margins 1 1 ESC H j 0 = Disabled
1 = Enabled
Check Digit Status 1 1 ESC H h 0 = Disabled
1 = Enabled
Check Digit
Transmission
1 1 ESC H k 0 = Disabled
1 = Enabled
