HOST MODE PROGRAMMING
52
4
PARAMETER TYPE SEL STRING DATA
Last Read Code TX 1 1 ESC K R 0 = Disabled
1 = Enabled
2 = Enabled With Code Center
3 = Enabled With Code Center And
Bounds
USB CONNECTOR MODELS
PARAMETER TYPE SEL STRING DATA
CODE COLLECTION
Code Collection Mode 1 1 ESC J A 0 = Within an Image
1 = Within a Phase
Number of Codes 0 ESC J B Range: 1 to 200
Multiple Read 1 1 ESC J D 0 = Disabled
1 = Enabled
Code Collection Filters 1 1 ESC J C 0 = Disabled
1 = Enabled
CODE FILTER SETTING (DEPTH: n = 1 to 10)
Status #n 1 1 ESC p #n 0 = Disabled
1 = Enabled
Symbology #n 1 1 ESC q #n 0 = Interleaved 2 of 5
1 = Code 39
2 = Code 39 Full ASCII
3 = Codabar
4 = Code 128
5 = GS1-128 (ex EAN 128)
6 = Code 93
7 = EAN-13
8 = EAN-8
9 = UPC-A
10 = UPC-E
11 = EAN-13 Addon 2
12 = EAN-8 Addon 2
13 = UPC-A Addon 2
14 = UPC-E Addon 2
15 = EAN-13 Addon 5
16 = EAN-8 Addon 5
17 = UPC-A Addon 5
18 = UPC-E Addon 5
19 = Data Matrix ECC200
20 = PDF417
21 = QR Code
22 = Maxicode
23 = Australia Post
24 = POSTNET
25 = PLANET
26 = Japan Post
27 = KIX Code
28 = Royal Mail
29 = GS1 DataBar Expanded
30 = GS1 DataBar Expanded Stacked
31 = GS1 DataBar Limited
32 = GS1 DataBar
33 = GS1 DataBar Stacked
34 = Micro PDF417
To Next Page
