Datalogic Matrix 210 Programming Manual

MATRIX 210™ PARAMETERS LIST
67
4
PARAMETER TYPE SEL STRING DATA
TX Refresh Timeout
(sec)
1 1 ESC T S 0 = 1
1 = 2
2 = 5
3 = 10
4 = 30
5 = 60
6 = 180
Auxiliary Port 1 1 ESC T T 0 = Disabled
1 = Enabled
Main Port 1 1 ESC T U 0 = Disabled
1 = Enabled
Fieldbus Port 1 1 ESC T V 0 = Disabled
1 = Enabled
Ethernet Data Socket 1 1 ESC T W 0 = Disabled
1 = Enabled
FORMAT
Header String 2 ESC T X Length: 0 to 128
Terminator String 2 ESC T Y Length: 0 to 128
Heartbeat Message
Format
1 1 ESC T n 0 = Internal Numeric Messages
1 = User Defined Messages
PARAMETER TYPE SEL STRING DATA
Diagnostics Message
Format
1 1 ESC T Z 0 = Internal Numeric Messages
1 = User Defined Messages
Heartbeat Add Node
Address
1 1 ESC T p 0 = Disabled
1 = Enabled
USER DEFINED MESSAGES
Slave No Reply 2 ESC T a Length: 0 to 128
Slave Address
Duplication
2 ESC T b Length: 0 to 128
Slave Net Configuration 2 ESC T c Length: 0 to 128
Local Network Failure 2 ESC T d Length: 0 to 128
FieldBus
Communication Failure
2 ESC T e Length: 0 to 128
FieldBus Type Mismatch 2 ESC T f Length: 0 to 128
Fieldbus Configuration
Error
2 ESC T g Length: 0 to 128
Fieldbus DHPC Problem 2 ESC T h Length: 0 to 128
Wrong Rotary Switch
Selection
2 ESC T i Length: 0 to 128
CBX BM100
Communication Failure
2 ESC T j Length: 0 to 128
Hearbeat Message 2 ESC T o Length: 0 to 128
USB CONNECTOR MODELS
PARAMETER TYPE SEL STRING DATA
HEARTBEAT
Status 1 1 ESC T k 0 = Disabled
1 = Enabled
