1D Symbologies Enter/Exit Programming Mode
Product Reference Guide
173
MSI Set Length 2
This feature specifies one of the bar code lengths for MSI Length Control on page 171. Length 2
is the maximum label length if in Variable Length on page 243 Mode, or the second fixed
length if in Fixed Length on page 243 Mode. Length includes the bar code’s check, data, and
full-ASCII shift characters. The length do
es no
t include start/stop characters.
The length can be set from 1 to 50 characters. A setting of 0 specifies to ignore this length
(onl
y one fixed length).
Table 22 provides examples for setting Length 2. See page 243 for detailed instructions on set-
ting this feature.
Table 22. MSI Length 2 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
00 (Ignore This
Length)
07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT MSI LENGTH 2 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘0’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select MSI Length 2 Setting
Make a mistake? Scan the CANCEL bar code to abort and not save
the entry string. You can then start again at the beginning.
CANCEL
DEFAULT
50 = Length 2 is 50 Characters
To Next Page
