Technical Specifications
274 QuickScan™ I QD24XX/QBT24XX/QM24XX
Base Station Indications (Cordless Models ONLY)
INDICATION LEDS
Power-up Complete Yellow LED on
Reader Disabled by the HOST or the communication
with H
OST is not established
Yellow LED blinking ~1Hz
Data/labels are transmitted to the HOST Yellow LEDs turned off for 100mSec
Programming Mode Yellow LED blinks quickly
Configuration alignment with the handheld is in prog-
ress
Red LED blinks quickly
Battery charging in progress Red LED on
Battery charging complete Green LED on
Battery charger error
Green LED and Red LEDs blink alternatively
~1Hz
No handheld
is placed on th
e cradle Red and Green LEDs off
Base Station Button Indicators
BUTTON PUSH
EVENT
CORDLESS
RED
INDICATOR(**)
GREEN
INDICATOR(**)
Push at power-up
force device connection
(A
laddin)
Off
Slow blink
Fast blink
< 5 sec Paging Off Fast blink
> 5 sec Unlink Off Slow blink
To push the button, insert a paper clip in the hole at the label in the bottom of the Base.
