1.5 TYPICAL APPLICATIONS
Example 1: Operating point protection on drilling machines
The operator positions the part and takes it back after machining. The operator must be protected against possible
abrasions while working.
Solution: SG 14mm safety light curtain is especially suitable for this kind of application, which requires the
installation of the device directly on the machine.
Advantages: Highly reduced profile size guarantees installation flexibility for machine dimensions.
Fig 5 - Operating point protection on drilling machines
Example 2: Bending presses
The safety device must protect the operator from being squashed between the top and bottom tool or the machined
part during the fast approach phase.
Solution: If only one beam of the safety light curtain is darkened while the press is moving down, the mobile tool
bar will stop.
Advantages: The safety light curtain can be used in most bending operations thanks to its easy installation and
compact dimensions.
As well as offering excellent reliability, SG ensures increased plant productivity as it reduces the dead times
necessary for machine accessing, adjustment and maintenance.
