7 FUNCTIONS
This chapter deals with all the functions of the light curtain.
7.1 TEST
The TEST function can be activated by keeping a normally open external contact (TEST push-button), open for at
least 0.5 seconds.
The TEST signal is active high.
Fig 36 - Test timings
