Some parts or sections of this manual containing important information for the user or installing operator are
preceded by a note:
This manual contains all the information necessary for the selection and operation of the safety devices.
However, specialised knowledge not included in this technical description is required for the planning and
implementation of a safety light curtain on a power-driven machine.
As the required knowledge may not be completely included in this manual, we suggest the customer to contact
Datalogic Technical Service for any necessary information relative to the functioning of the light curtains and the
safety rules that regulate the correct installation (cfr. USER INTERFACE AND DIAGNOSTICS page 42).
1.2 PACKAGE CONTENTS
Package contains the following objects:
 Receiver (RX)
 Emitter (TX)
 Quick Guide of safety light curtain
 Periodical checklist and maintenance schedule
 Mini-DVD with instruction manual and other documents
 4 angled fixing brackets and specific fasteners
 2 additional angled fixing brackets for models with heights included between 1200 and 1800 mm
Notes and detailed descriptions about particular characteristics of the safety devices in
order to better explain their functioning. Special instructions regarding the installation
process.

Datalogic SG4-30-015-OO-E Specifications

General

Brand	Datalogic
Model	SG4-30-015-OO-E
Category	Security Sensors
Language	English
