2 INSTALLATION
2.1 PRECAUTIONS TO BE OBSERVED FOR THE CHOICE AND INSTALLATION
Use only matched emitter and receiver pairs with same serial no.
The outputs (OSSD) of the ESPE must be used as machine stopping devices and not as command devices.
The machine must have its own START command.
The dimension of the smallest object to be detected must be larger than the resolution level of the device.
The ESPE must be installed in an environment complying with the characteristics indicated in TECHNICAL
DATA page 49.
The ESPE must not be installed close to strong and/or flashing light sources, in particular close to the front
window of receiving unit.
The presence of intense electromagnetic disturbances could affect device’s correct operation.
This condition shall be carefully assessed with the advice of DATALOGIC Technical Service.
The operating distance of the device can be reduced in presence of smog, fog or airborne dust.
A sudden change in environment temperature, with very low minimum peaks, can generate a small
condensation layer on the lenses and thus jeopardize correct operation.
Make sure that the protection level assured by the light curtain device is compatible
with the real danger level of the machine to be controlled, according to EN ISO 13849-1:
2015 or EN 62061:2005/A2: 2015.
