Datalogic Skorpio X3 User Manual

135
Universal Product Code-A (UPC-A)
Defaults
Scanner
Type
Code
Parameter
Description
I.D.# Accept. Input
Min
Max
Factory
Laser
2D Imager
Enter 1 for On and 0 for Off
Enable
Enables/disables the
UPC-A symbology.
0500 On or Off Off On On √ √
Enable
Aggressive
Decoding
Enables more aggressive
decoding algorithms to be
used in order to scan hard
to read labels.
0501 On or Off Off On Off √ √
Send
Check Digit
Includes check digit in the
label which is transmitted.
0502 On or Off Off On Off √ √
Send System
Digit
Includes the system digit
in the label transmission.
For UPC-A, the system
digit is always zero.
0503 On or Off Off On On √ √
Convert
UPC-A to
EAN-13
Instructs the decoder to
expand UPC-A labels to
their EAN-13 equivalents.
Any EAN-13 parameters
will then apply to the
result.
0504 On or Off Off On Off √ √
Read
Verification
Sets the number of times
a label must be read
before it is transmitted.
0520 01 - 04 01 02 01 √
User ID
Specifies the symbology
identifier (if any) that is
sent when parameter
Send Code ID (Index
0025) is set to 3. ASCII
code zero (null) is used to
indicate that an identifier is
not to be sent for the
symbology.
0521
Any
single
ASCII
character
(00 = Off)
‘A’ ‘A’ ‘A’ √ √

Datalogic Skorpio X3 Specifications

General

Display diagonal	3.2 \
Display resolution	240 x 320 pixels
Display number of colors	-
Flash memory	0.512 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	microSD (TransFlash), microSDHC
Processor family	PXA 310
Processor frequency	0.624 GHz
GPS (satellite)	No
Operating system installed	Windows Embedded CE 6.0
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Security algorithms	CCX v4
Interface	USB 1.1, RS-232, micro USB
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Battery capacity	3000 mAh
Product color	Black
Keypad number of keys	38

Weight and Dimensions

Depth	156 mm
Width	76 mm
Height	193 mm
Weight	482 g
