Connections
User’s Manual 187
Connect the Single Slot Dock to the peripheral by means of a
Micro-A USB cord, or use a Micro-A to Std-A receptacle USB adapter
such as Datalogic 94A051969 (together with a standard USB cable
*
if needed).
* A standard USB cable is needed only if the USB hard driver or flash memory device does
not include its own cable with a "A" plug on it.
NOTE
Skorpio X4 works with most of the mentioned USB
peripherals. Datalogic cannot guarantee the
interoperability of Skorpio X4 with all devices on the
market.
NOTE
Connection complies to USB 2.0 standard.
NOTE
The actual data transfer speed can be appreciably lower
than the maximum theoretical speed.
USB hard drive/
external memory source
94A051969
Micro-USB
Host Cable
Skorpio X4 Single Slot Dock
Standard
A to Micro A
USB Cable*
Power
Supply
To Next Page
