Connections
186 Skorpio™ X4
Connection to USB Peripherals
You can connect the Skorpio X4 to a standard 101-key USB keyboard
or to a standard USB flash memory device. Connect the terminal to a
standard USB cable or to the Datalogic 94A051971 HandyLink
Micro-USB host cable (together with a standard USB cable
*
if
needed). For all these devices maximum current draw must be less
than 100mA.
* A standard USB cable is needed only if the USB hard driver or flash memory device does
not include its own cable with a "A" plug on it.
Keyboard with USB interface
Standard USB cable
Skorpio X4
USB hard drive/
external memory source
94A051971 HandyLink
Micro-USB Host Cable
Skorpio X4
Standard
A to Micro A
USB Cable*
