Datamax Label Printer User Manual

Maintenance
Ovation2 29
3.1 Cleaning the Printhead
Warning: Turn ‘off’ the printer and unplug the unit from
the outlet before cleaning the printhead.
1. Turn ‘off’ the printer and open the cover.
2. Push the printhead latch back toward the back of the printer and
raise the printhead carrier assembly.
3. Using a cotton swab dipped in isopropyl alcohol, rub the cotton
swab along the printhead.
Figure 3-1 Cleaning the Printhead
Note: The printhead should be cleaned every time a new roll of media
is installed.

Datamax Label Printer Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi, 300 dpi
Media Type	Labels, tags, receipts, or tickets
Media Thickness	0.0025 in (0.0635 mm) to 0.010 in (0.254 mm)
Connectivity	USB, Serial, Ethernet
Storage Temperature	140°F (-40°F to 60°C)
Power Requirements	100-240 VAC
Dimensions	Varies by model
Weight	Varies by model
