Datamax M-Class Mark II M-4206 User Manual

M-4206 21
4.5.2 Menu Items and Values
The table below details the Printer Setup Menu List items with a brief description of the item’s function, and the possible
values. A “*” denotes the default setting.
1) MEDIA TYPE
Sets printing for direct thermal (no
ribbon) or thermal transfer (ribbon)
media.
Possible Values:
* DIRECT THERMAL
THERMAL TRANSFER
2) SENSOR TYPE
Selects the sensor type used to detect the
media’s Top Of Form (TOF) mark.
Possible Values:
* EDGE: gap / notch TOF marks
REFL (Reflective): black marks
CONT (Continuous): no TOF marks
3) PRESENT SENSOR
Enables/Disables the optional
Present Sensor feature.
Possible Values:
*AUTO
NO
YES
4) CUTTER EQUIPPED
Enables/Disables the optional Media
Cutter feature.
Possible Values:
*AUTO
NO
YES
5) SOP ADJUST
Sets the start of print (SOP) location,
relative to the top of form.
Possible Values:
Range: 0 – 255; nominal = *128
(0 = close to edge; 255 = farthest
from edge)
6) PRESENT ADJUST
Specifies an additional amount to feed
the label after printing.
Possible Values:
Range: 0 – 255; nominal = *128
(0 = close to edge; 255 = farthest from
edge)
7) BAUD RATE
Sets the serial port baud rate. (Must
match the host setting).
Possible Values:
600 to 38.4k; default = *9600 BPS
8) DATA BITS
Sets the serial data word length (Must
match the host setting).
Possible Values:
*8
7

Datamax M-Class Mark II M-4206 Specifications

General

Print Resolution	203 dpi
Print Method	Thermal Transfer and Direct Thermal
Max Print Width	4.25 inches
Max Print Speed	6 ips
Memory	8 MB Flash
Interfaces	Serial, Parallel, USB
Media Sensor	Reflective and Transmissive
Media Types	Labels, Tags
Label Roll Diameter	8 inches
Label Thickness	0.0025 to 0.01 inches
Maximum Print Length	99 inches
