M-4206 3
1.1.2 Optional Features
Thermal Transfer
A printing method that uses ribbon to produce exceptional image clarity, as compared to most direct thermal media
types. This option must be specified for use with either ‘coated side in’ ribbon or ‘coated side out’ ribbon.
Media Cutter
A rotary-type mechanism to automatically cut material with a maximum thickness of .010” (.254 mm) into minimum
lengths of 1.25 inches (31.8 mm).
Peel and Present Mechanism (requires the Internal Rewind option)
An output control device that automatically separates printed labels from the backing material and allows subsequent
printing to occur only after the removal of a previously printed label. Minimum label length is 1.5 inches (38 mm).
Internal Rewind
An internal mechanism to wind four-inch outer diameter rolls of printed labels, or the label backing material when
using the Peel and Present option.
Present Sensor
An output control device that allows subsequent printing to occur only after the removal of a previously printed label.
External Keyboard (specify voltage / country requirement when ordering)
A portable keyboard / display terminal, the DMX Passport™, for stand-alone printing.
External Ethernet Connectivity (uses printer’s parallel port)
The DMX100 External Print Server is an external Network Interface Controller (NIC) that enables the printer to
provide Ethernet
connectivity.
FLASH Memory Expansion (requires new main PCB)
An optional main PCB assembly is available with 4MB Flash memory expansion for International Language Printing
Capability (ILPC) and/or additional fonts and graphics.
ILPC
The International Language Print Capability consisting of one of the following:
¾ CG-Times (western European) Scalable font
¾ Kanji Gothic B Scalable font
¾ Simplified Chinese GB Scalable font
¾ Korean Hangul font
