68 M-4206
direct thermal media Media coated with special chemicals that react and darken with the application of heat.
DPI (dots per inch) A measurement of print resolution, rated in the number of thermal elements contained in one
inch of the printhead. Also referred to as “resolution”.
DPL (Datamax Programming Language) programming commands used specifically for control of and label
production in Datamax printers. A complete listing of commands can be found in the Programmer’s
Manual.
fan-fold Media that is folded and stacked.
feed speed The speed at which the media moves under the printhead in non-printed areas and between labels.
Flash memory Non-volatile memory (does not require printer power to maintain data) that can be erased and
reprogrammed, used to hold the printer’s operating programs.
font A set of alphanumeric characters that share a particular typeface.
gap A space between die-cut or notched labels used to sense the top of form.
IPS (inches per second) Imperial measurement of printer speeds.
label A paper or synthetic printing material, typically with a pressure sensitive adhesive backing.
label length The distance from the top of the label to the bottom of the label as it exits the printer.
label repeat The distance from the top of one label to the top of the next label.
label tracking Excessive lateral (side to side) movement of the media as it travels under the printhead.
label width The left to right measurement of the label as it exits the printer.
mark Generalized term to indicate the label top of form light.
media Generalized term for all types of printing stocks, including: roll fed, continuous, die-cut, reflective, and
fanfold.
media hub Device in the printer used to support roll media.
media sensor An electronic device equipped with photosensors to detect media and the top of form on die-cut,
notched or reflective media.
