Datamax M-Class Mark II User Manual

Chapter 3 - Printer Operation 22
3
3
3
.
.
.
6
6
6
U
U
U
s
s
s
e
e
e
r
r
r
-
-
-
D
D
D
e
e
e
f
f
f
i
i
i
n
n
n
e
e
e
d
d
d
L
L
L
a
a
a
b
b
b
e
e
e
l
l
l
The User-Defined Label allows a template to be populated by variable data (via the printer’s
control panel or a USB QWERTY keyboard). The template is a stored label format, where fields
delimited by an ampersand (&) become variable.
The printer will prompt you to enter the variable field data. For example, the stored label format
could contain the data 19131423443&ENTER NAME&
Afterward, when recalled from memory, the display will indicate the variable field: ENTER NAME

•
Variable data can be any part of the DPL format - font ID, positioning, etc.
• No error checking will be performed.
• Supports .dlb, .dpl, .prn, and .txt file types.

Datamax M-Class Mark II Specifications

General

Media Sensor	Adjustable reflective and transmissive sensors
Print Method	Thermal Transfer
Print Resolution	203 dpi
Memory	8 MB Flash, 16 MB SDRAM
Interface Options	USB, Serial, Ethernet, Parallel
Media Type	Roll-fed, die-cut, continuous, fan-fold, tags, ticket stock
Media Width	1.0 in (25.4 mm) to 4.65 in (118 mm)
Media Thickness	0.0025 in (0.0635 mm) to 0.010 in (0.254 mm)
Media Roll Diameter	8 inches (203 mm) max
Ribbon Width	1 to 4.33 inches (25.4 to 110 mm)
Ribbon Length	1968 ft (600 m)
Ribbon Core	1 inch (25.4 mm)
Label Width Range	1.0 in (25.4 mm) to 4.65 in (118 mm)
Label Length Range	0.25 to 39 inches (6.35 to 991 mm)
