Datamax M-Class Mark II User Manual

Appendix A – Specifications 70
Media/Ribbon
Media Types Roll-Fed, Die-Cut, Continuous, Fan-Fold
Max. Media Width 4.65" (118 mm)
Min. Media Width 1.0" (25 mm)
Max. Print Width 4.25” (108 mm) M-4206 & M-4210
4.16” (105.7mm) M-4306
Print Length Range .25 - 99" (6 - 2475 mm)
Media Thickness Range .0025 - .01" (.064 mm - .254 mm)
Media Supply Roll Capacity 8" (203 mm) O.D. on a 3.0" (76.2 mm) core
7" (178mm) O.D. on a 1.5” (38mm) core
Ribbon Width Range
1.0 - 4.5" (25 - 114 mm)
Ribbon Roll Capacity Matched to media: approx. 1476’ (450 m) long
Ribbon Core: 1.010” ± .006” (25.6 mm ± .2 mm) inner diameter.
Communications
Interface USB, RS-232 (DB-9), and IEEE 1284 Compliant Centronics Parallel
Baud Speed 600 to 38,400 bits per second (BPS)
Handshaking Xon/Xoff, CTS, DTR
Parity Even, Odd, or None
Stop Bits 1 or 2
Data Bits 7 or 8
Embedded Fonts and Barcodes
The printer is equipped with the most popular industry fonts and bar codes; see the Class Series 2
Programmer’s Manual for full listings and detailed information.
Non-display printers Display-equipped printers
 9 Bit Map Fonts; rotated 0, 90, 180, 270
degrees.
 10 smooth bitmap fonts 6pt – 48pt
 9 Bit Map Fonts; rotated 0, 90, 180, 270
degrees.
 10 smooth bitmap fonts 6pt – 48pt
 AGFA Scalable Font Engine featuring CG
Triumvirate™ regular and bold-condensed
scalable fonts with dynamic font attributes.

Datamax M-Class Mark II Specifications

General

Media Sensor	Adjustable reflective and transmissive sensors
Print Method	Thermal Transfer
Print Resolution	203 dpi
Memory	8 MB Flash, 16 MB SDRAM
Interface Options	USB, Serial, Ethernet, Parallel
Media Type	Roll-fed, die-cut, continuous, fan-fold, tags, ticket stock
Media Width	1.0 in (25.4 mm) to 4.65 in (118 mm)
Media Thickness	0.0025 in (0.0635 mm) to 0.010 in (0.254 mm)
Media Roll Diameter	8 inches (203 mm) max
Ribbon Width	1 to 4.33 inches (25.4 to 110 mm)
Ribbon Length	1968 ft (600 m)
Ribbon Core	1 inch (25.4 mm)
Label Width Range	1.0 in (25.4 mm) to 4.65 in (118 mm)
Label Length Range	0.25 to 39 inches (6.35 to 991 mm)
