Datamax M-Class Mark II User Manual

Chapter 5 – Maintenance and Adjustments 57
File Handling Messages (Continued)
Displayed
Message
Description Possible Solution(s)
NO FILES
AVAILABLE
No associated files can
be found to perform
the requested action.
Ensure the file is present:
• Following a Print File request, this is normal when no
files are available for printing (also note that some
files will print only the file name);
• Following a Process File request, this is normal when
no files are available for processing (also note that
some files may not display); or,
• Following a Copy File request, this is normal when no
files are available for copying (also note that internal
database files cannot by copied).
NOT SUPPORTED
The file type
requested is not
supported.
Recheck the type of file requested for printing or
processing, and ensure that it matches one of the
available types for that function.
PROTECTED,
COPY FILE?
The file requested will
be copied to a
protected module.
Select YES to override protection and copy the file, or
NO to exit.
UNFORMATTED
The module is
unformatted.
Format the module.
FORMAT MODULE will erase all data in the
selected memory.

Datamax M-Class Mark II Specifications

General

Media Sensor	Adjustable reflective and transmissive sensors
Print Method	Thermal Transfer
Print Resolution	203 dpi
Memory	8 MB Flash, 16 MB SDRAM
Interface Options	USB, Serial, Ethernet, Parallel
Media Type	Roll-fed, die-cut, continuous, fan-fold, tags, ticket stock
Media Width	1.0 in (25.4 mm) to 4.65 in (118 mm)
Media Thickness	0.0025 in (0.0635 mm) to 0.010 in (0.254 mm)
Media Roll Diameter	8 inches (203 mm) max
Ribbon Width	1 to 4.33 inches (25.4 to 110 mm)
Ribbon Length	1968 ft (600 m)
Ribbon Core	1 inch (25.4 mm)
Label Width Range	1.0 in (25.4 mm) to 4.65 in (118 mm)
Label Length Range	0.25 to 39 inches (6.35 to 991 mm)
