MICROFLASH 4TE PRINTER USER'S GUIDE
8
Printing a Self-Test
1. After installing the paper, open the printer's cover.
2. Press and hold the red, self-test button for
approximately five seconds until printing begins.
3. After printing begins, release the red, self-test
button.
Configuring the Printer
The printer has many configurable settings. To
configure or upgrade firmware, download the
Windows configuration program.
Using Printer Data Cables
1. Select the appropriate cable for use with the host
and/or device you are using.
2. Insert the plug into the printer's data port
(Figure 14).
3. Lead the cable through the notch on the outside of
the printer's cover.
4. With the cable exiting the front of the printer, close
and latch the printer's cover.
Caution: If the red, battery isolator labels are
installed, remove them.
To Next Page
