Datamax MICROFLASH 4TE User Manual

MICROFLASH 4TE PRINTER USER'S GUIDE
6
Installing Paper
1. Insert a roll of paper with the end of the roll exiting
from the bottom of the paper cavity (Figure 8).
2. Open the print head by raising the gray, print head
release lever until it is fully open. Do not stop at the
partial open position (Figure 9).
3. Wake up the printer by briefly pressing the red, self-
test button (Figure 10).
4. Feed the end of the paper under the roller. The
paper automatically feeds under the roller and exits
the top of the print head. Verify the paper exits the
print head straight (Figure 11).
Figure 8
Figure 9
Figure 10 Figure 11

Datamax MICROFLASH 4TE Specifications

General

Brand	Datamax
Model	MICROFLASH 4TE
Category	Printer
Language	English
