6
Repeater Configuration/Architecture
Vantage Pro2 wireless repeaters are used to enhance the transmission range and
capabilities between a station, or multiple stations, and a receiver (console, Envoy, or
Vantage Connect). A repeater receives signals transmitted from a Vantage Pro2 station
and retransmits it to a console, wireless Weather Envoy, Envoy8X, Vantage Connect or
another repeater. Depending on transmission distance, one repeater or several repeaters
can be used to collect and retransmit weather data.
This section describes some of the repeater transmission situations and station networks
in which a repeater or set of repeaters can be used.
Repeater Architecture
Two repeater configurations are discussed in this section:
• Single Repeater Configuration — Any situation in which one repeater is needed to
transmit data from one station to one receiver (i.e., console or Envoy).
• Advanced Repeater Configuration — Any architecture where one or more stations
and/or one or more repeaters are combined to form a network of repeaters. For
example, if a station is placed further away from a console than the range of a single
repeater, multiple repeaters can be set up across the distance to transmit weather data
to the console in a chain. Another advanced repeater configuration might involve one
or more stations transmitting to a repeater. It is also possible to create a network using
a combination of multiple transmitters and repeaters.
Note: All range estimates used in the examples below are based on the idea that the distance between a
station and a repeater is a “radio-link”. See “Wireless Repeater Introduction” on page 4 for more
information about the real-world range of a radio-link.
