35
ES-1203 Cod. 420120253 REV. 1.0
MECHANICAL AND ACOUSTIC FEATURES
DIMENSIONS
ACOUSTIC COVERAGE
The measurements of the ES1203 system are:
SUBWOOFER: 360 mm x 680 mm x 545 mm
TOP: 110 mm x 460 mm x 160 mm
The acoustic coverage of a single ES1203 top
is 60° (vertical) and 97° (horizontal). The coverage
is asymmetrical.
When the two tops are mounted one on top of
the other (see the related section), you can use
digital steering to direct the coverage upwards
or downwards (selectable through the user
interface).
