dBTechnologies ES 1203 - Operating Temperature and Processor; User Interface and I;O; Power Supply Specifications

59
ES-1203 Cod. 420120253 REV. 1.0
PROCESSOR
INPUTS AND OUTPUTS
USER INTERFACE
Consumption at 1/8 of the power
under normal operating conditions
(*):
1.1 A (220 - 240 V~) - 2.2 A (100 - 120 V~)
Consumption at 1/3 of the power
under maximum operating
conditions (**):
2.1 A (220 - 240 V~) - 4.5 A (100 - 120 V~)
Consumption with speaker on and no
signal (idle):
26 W
Inrush current:
9.15 A (230 V~)
POWER SUPPLY SPECIFICATIONS (CONSUMPTION / INSTALLATION)
* NOTE FOR THE INSTALLER: Values refer to 1/8 of the power under normal operating conditions (musical program with rare or no clipping).
For any conguration type, we recommend considering them to be the minimum values for dimensioning.
** NOTE FOR THE INSTALLER: Values refer to 1/3 of the power under heavy operating conditions (musical program with frequent clipping
and limiting). We recommend dimensioning according to these values for installations and professional tours.
Internal controller:
28/56 bit DSP
A/D D/A converter:
24 bit/48 kHz
Limiter:
Peak, RMS, Thermal
Controls:
OLED display, push/rotary encoder
Inputs:
1 x Combo (XLR/Jack) MIC/INSTRUMENT, 2 x Combo (XLR/Jack) MIC/LINE
Built-in input:
1x Bluetooth®
Output:
1 x XLR output
OPERATING TEMPERATURE
Temperature Range (ambient):
-10 +50 °C
English
