Figure 24 – AES3 in to AES3 out, 44.1 kS/s
AES3 Reference Out is also related to the phase of Clk In. The scope shots
below were taken with the unit sync’d to Clk In
Figure 25 – Word Clock In to AES3 Reference Out, 96 kS/s
Figure 26 – Word Clock in to AES3 Reference Out, 44.1 kS/s
