Analogue Interface Specifications
Balanced Outputs
Type Balanced, semi-floating
Format AES14 : 1992
Source Impedance < 3
Ω
(20Hz - 20kHz)
Maximum Load 600
Ω
Noise, unweighted < -110 dB0
(20Hz – 20kHz)
Spurious responses < -100 dB0
(20Hz - 20kHz) -110 dB0, typ
Signal Balance @ 1kHz > 40 dB, spec
50Hz 45 dB, typ
1kHz 53 dB, typ
20kHz 53 dB, typ
L – R crosstalk < -100 dB0
(20Hz- 20kHz)
Level for Full Scale +14 dBu
(as shipped)
Trim range ±6 dB
Connector type XLR3 male
Connections Pin 1 Ground or shield
Pin 2 +Signal
Pin 3 -Signal
Table 7 – Balanced Output Details
Unbalanced
Outputs
Type Unbalanced, ground referred
Source Impedance 52
Ω
Maximum Load 600
Ω
Noise, unweighted < -110 dB0, spec
(20Hz – 20kHz)
Spurious responses < -100 dB0
(20Hz - 20kHz)
Level for Full Scale +8 dBu
Connector type RCA phono
Table 8 – Unbalanced Output Details
