Digital Interface Specifications
AES/EBU (AES3)
Input Output
Type Balanced, differential
Impedance 110 110
Ω
Sensitivity (unloaded) 1 ~ 10 7 V pk-pk
Maximum Wordlength 24 24 bits
Damage level > 20 V pk-pk
Connector XLR3 female XLR3 male
Pin 1 Ground or shield
Pin 2 +Signal
Connections
Pin 3 -Signal
Table 4 – AES/EBU i/o specifications
SDIF-2, SDIF-3 and
DSD
Input Output
Type Single ended, ground
referred
Impedance 100 25
Ω
Sensitivity (unloaded) TTL TTL
Maximum Wordlength 24 24 bits
Damage level > 10 V pk-pk
Time skew
Word Clock in / out < 40 ns
Connector BNC x 3 BNC x 1
CH1 (left)
CH2 (right)
Connections
Clk In & Out
Table 5 – SDIF-2, SDIF-3 and DSD i/o specifications
Remote control interface
Input / Output
Type RS-232
Level RS-232
Baud Rates 1200, 2400, 4800, 9600
Data Format
Contact dCS
Connector 9 way D type male
Table 6 – Remote Control Interface Details
