Transmit -> [8][REQUEST_DSD_MODE]
Response -> [ACK immediate][8], actual mode
Transmit -> [9][REQUEST_DSD_MODE]
Response -> [ACK immediate][9], actual mode
11) Check ADCs for mode change. This command allows the Transmitter to
check the mode of the ADCs. If a unit has not changed the transmitter
should go back to step 9 and repeat the command.
Transmit -> [2][REQUEST_DSD_MODE]
Response -> [ACK immediate][2], actual mode
Transmit -> [3][REQUEST_DSD_MODE]
Response -> [ACK immediate][3], actual mode
Transmit -> [4][REQUEST_DSD_MODE]
Response -> [ACK immediate][4], actual mode
Transmit -> [5][REQUEST_DSD_MODE]
Response -> [ACK immediate][5], actual mode
The system should now be set up with the Master Clock configured for 44.1k
operation and the ADCs and DACs locked in P3D mode.
