Clocking 2x word clock input on 2x BNC connector:
• Accept standard word clocks at 44.1kHz, 48kHz, 88.2kHz, 96kHz,
176.4kHz or 192kHz.
• The data rate can be the same as the clock rate or an exact multiple
(0.25x, 0.5x, 1x, 2x, 4x, 8x) of the clock rate.
• Sensitive to TTL levels.
MQA Full decoding and rendering of MQA data from the Network and the USB
Type-A inputs.
Final rendering of unfolded MQA data only from the other inputs.
Frequency response (set
to Filter 1)
Fs = 44.1 or 48kS/s +/-0.1dB, 10Hz to 20kHz
Fs = 88.2 or 96kS/s +/-0.1dB, 10Hz to 20kHz -3dB @ >38kHz
Fs = 176.4 or 192kS/s +/-0.1dB, 10Hz to 20kHz -3dB @ >67kHz
Fs = 352.8 or 384kS/s +/-0.1dB, 10Hz to 20kHz -3dB @ >100kHz
DSD64 +/-0.1dB, 10Hz to 20kHz -3dB @ >90kHz
DSD128 +/-0.1dB, 10Hz to 20kHz -3dB @ >100kHz
Residual noise (6V output
setting)
16-bit data: Better than –96dB0, 20Hz - 20kHz unweighted.
24-bit data: Better than –113dB0, 20Hz - 20kHz unweighted.
Upsampling Multi-stage DXD oversampling with switchable DSD upsampling (1-bit
2.822 or 3.07MS/s).
Spurious responses Better than –105dB0, 20Hz - 20kHz.
L-R crosstalk Better than –115dB0, 20Hz - 20kHz.
Line outputs 1 stereo balanced pair on 2x 3-pin male XLR connectors (pin 2 = hot, pin 3
= cold). These outputs are electronically balanced and floating, the signal
balance ratio at 1kHz is better than 40dB. Output impedance is 3Ω ,
maximum load is 600Ω (a 10kΩ - 100kΩ load is recommended).
1 stereo unbalanced pair on 2x RCA Phono connectors. Output impedance
is 52Ω , maximum load is 600Ω (a 10kΩ - 100kΩ load is recommended).
Output levels are 2V or 6V rms for a full-scale input, set in the menu.
Shipping dimensions 320mm (H) x 360mm (W) x 530mm (D)
Shipping weight 10.3kg
Product dimensions 121.5mm (H) x 220mm (W) x 339mm (D)
Product weight 7.4kg
Power requirements 90-120V / 220-240V, 50/60Hz
Power consumption:30W
These specifications are subject to change without notice.
Specifications
