XAEF - Extended-EV message Formats
Qualifiers: Q, S, R.
This message allows the creation and configuration of up to three sets of information
tags to be used by an event having the Message ID qualifier set to A, B or C. The
message has the following format:
A[BBB...]
o A: Identifier of the extended-EV format being set or consulted. The valid
identifiers are: A, B or C.
o [BBB...]: Information tag. Enter each tag separated by a ";" character. The valid
tags are:
 AC: Instant acceleration measured in Miles per hour per seconds.
 AL: Altitude in meters above mean sea level (AMSL).
 BL: Battery voltage level. Milivolts.
 CF: Cell information.
 CVxx: Counter xx value.
 DOP: GPS dilution of precision.
 IO: Inputs and Outputs state.
 IP: IP Address.
 SV: Satellites in view.
 VO: Virtual Odometer value. Meters.
For more information on each tag, refer to the Extended-EV Tags formats list on
the Event Message (EV) section.
Example:
To set event 49 to send an extended-EV message that includes the cell information,
the number of GPS satellites in view and the state of counter 05 whenever the
vehicle's speed goes above 55 mph:
Define the event. Set it to use extended-EV format A
>SED49NA0;S00+<
Define extended-EV format A to include the required tags
>SXAEFA;CF;SV;CV05<
To delete the extended-EV reporting format send
>SXAEFAU<
