Specifications
Power
 DC Voltage: 8V - 32 V
 Current consumption:
o With Internal battery at null charge (IDLE)
o Long term average: 50 mA @ 12V.
o Long term average while on power saving mode: 6mA @ 12V.
 Reverse voltage polarity protection.
 High transient voltage (as seen on automotive applications) protection.
 Thermal shutdown and current limit protection.
Inputs/Ignition
 3 Auxiliary Inputs + 1 Ignition Input. Max 30V.
 Impedance: 50 K-ohms (Pull-Up)
 1 Analog to Digital Input. 0V - 10V. This input has a protection against voltages greater
than 10V.
Outputs
 2 Open Drain Outputs.
 Continuous current capacity: 1.8A
 Maximum instantaneous current (< 1 sec): 10A
 Maximum switching voltage: 30V
 Over temperature shutdown at 165 C.
 Over current shutdown. The output restarts automatically after the over current state
finishes, this can take up to 5 seconds. The G07 signal transitions to True when the over
current state is detected.
 ESD protection.
Environment
 Charging temperature: 0 C to +45 C
 Operating temperature: -20 C to +70 C
 Storage temperature: -30 C to +85 C
 Humidity: up to 95% non-condensing
