DeDietrich MCA 45 - Page 37

5. To fill with water, use a filling tube with two tap connections, a rag
and a bleed key.
6. Connect the filling tube to a (cold) water tap.
7. Eliminate the air from the filling tube. Slowly fill the tube with
water. Hold the end of the tube up, above a bucket. Turn off the
tap as soon as water runs out of the pipe.
8. Unscrew the plug from the filling/draw-off valve.
The filling/draw-off valve is not necessarily located next to
the boiler.
T000845-A
T000846-A
T000847-A
T000848-A
MCA 45 - 65 - 90 - 115 6. Checking and maintenance
06/09/2010 - 300024828-001-A
36
